General Information of This Antibody-drug Conjugate (ADC)
ADC ID
DRG0ORLWR
ADC Name
40287441 3D1 MMAE
Synonyms
3D1 MMAE
   Click to Show/Hide
Organization
Dana-Farber Cancer Institute.; National Hospital Organization Tokyo Medical Center.; Keio University.
Drug Status
Investigative
Drug-to-Antibody Ratio
4
Structure
Antibody Name
MUC1 3D1
 Antibody Info
Antigen Name
Mucin-1 (MUC1)
 Antigen Info
Payload Name
Monomethyl auristatin E
 Payload Info
Therapeutic Target
Microtubule (MT)
 Target Info
Linker Name
Mc-Val-Cit-PABC
 Linker Info
Conjugate Type
Site-specific conjugation using new Q-tag substrate of bacterial transglutaminase
Combination Type
Vedotin
General Information of The Activity Data Related to This ADC
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Standard Type Value Units Cell Line Disease Model
Half Maximal inhibitory Concentration (lC50)
1.8
nM
CVCL_0031
Invasive breast carcinoma of no special type
Half Maximal inhibitory Concentration (lC50)
6.3
nM
CVCL_0031
Invasive breast carcinoma
Half Maximal inhibitory Concentration (lC50)
27
nM
CVCL_0031
Invasive breast carcinoma of no special type
Full List of Activity Data of This Antibody-drug Conjugate
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50) 1.8 nM Positive MUC1-C expression (MUC1-C+++/++)
Method Description
Cells were seeded at a density of 1500-3500 cells per well in 96-well plates. The next day, the cells were treated with different concentrations of the drug. Cell viability and proliferation were assessed using the Alamar Blue Reagent (cat# DAL1100, Thermo Fisher Scientific) following the company protocol. The IC50 values were determined by nonlinear regression of the dose-response data using Prism 10.0 (SCR_002798, GraphPad Software). Fluorescence intensity (560 nm excitation/590 nm emission) was measured in at least triplicate wells.

   Click to Show/Hide
In Vitro Model Invasive breast carcinoma of no special type MCF-7 cells (ER (D538G)) CVCL_0031
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50) 6.3 nM Positive MUC1-C expression (MUC1-C+++/++)
Method Description
Cells were seeded at a density of 1500-3500 cells per well in 96-well plates. The next day, the cells were treated with different concentrations of the drug. Cell viability and proliferation were assessed using the Alamar Blue Reagent (cat# DAL1100, Thermo Fisher Scientific) following the company protocol. The IC50 values were determined by nonlinear regression of the dose-response data using Prism 10.0 (SCR_002798, GraphPad Software). Fluorescence intensity (560 nm excitation/590 nm emission) was measured in at least triplicate wells.

   Click to Show/Hide
In Vitro Model Invasive breast carcinoma MCF-7 cells CVCL_0031
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50) 27 nM Positive MUC1-C expression (MUC1-C+++/++)
Method Description
Cells were seeded at a density of 1500-3500 cells per well in 96-well plates. The next day, the cells were treated with different concentrations of the drug. Cell viability and proliferation were assessed using the Alamar Blue Reagent (cat# DAL1100, Thermo Fisher Scientific) following the company protocol. The IC50 values were determined by nonlinear regression of the dose-response data using Prism 10.0 (SCR_002798, GraphPad Software). Fluorescence intensity (560 nm excitation/590 nm emission) was measured in at least triplicate wells.

   Click to Show/Hide
In Vitro Model Invasive breast carcinoma of no special type MCF-7 cells (ER (Y537S)) CVCL_0031
References
Ref 1 MUC1-C dependency in drug resistant HR+/HER2- breast cancer identifies a new target for antibody-drug conjugate treatment
