General Information of This Payload
Payload ID
PAY0SLCNJ
Name
WO2025015586A1, ADC25, Payload
Synonyms
compound 2
   Click to Show/Hide
Target Toll-like receptor 7 (TLR7); Toll-like receptor 8 (TLR8)
Structure
Formula
C24H31N7O3
Isosmiles
CCCCC(N1OCCCCNC2=C(NCCN)C(C2=O)=O)=NC3=C1C4=CC=CC=C4N=C3N
InChI
InChI=1S/C24H31N7O3/c1-2-3-10-17-30-20-21(15-8-4-5-9-16(15)29-24(20)26)31(17)34-14-7-6-12-27-18-19(28-13-11-25)23(33)22(18)32/h4-5,8-9,27-28H,2-3,6-7,10-14,25H2,1H3,(H2,26,29)
InChIKey
QCKUCHDPIVOPGV-UHFFFAOYSA-N
Pharmaceutical Properties
Molecule Weight
465.558
Polar area
150.18
Complexity
1316.280634
xlogp Value
1.7968
Heavy Count
34
Rot Bonds
13
Hbond acc
10
Hbond Donor
4
The activity data of This Payload
Standard Type Value Units Cell line Disease Model Cell line ID Reference
The minimum effective concentration (MEC) 0.0152 uM
peripheral blood mononuclear cells (PBMCs)
Normal
CVCL_0140
[1]
The minimum effective concentration (MEC) 0.0152 uM
peripheral blood mononuclear cells (PBMCs)
Normal
CVCL_0140
[1]
The minimum effective concentration (MEC) 0.0457 uM
peripheral blood mononuclear cells (PBMCs)
Normal
CVCL_0140
[1]
The minimum effective concentration (MEC) 0.0457 uM
peripheral blood mononuclear cells (PBMCs)
Normal
CVCL_0140
[1]
Each Antibody-drug Conjugate Related to This Payload
Full Information of The Activity Data of The ADC(s) Related to This Payload
cN113943310A ADC-12 [Investigative]
Discovered Using Cell Line-derived Xenograft Model
Click To Hide/Show 1 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [2]
Efficacy Data Tumor Growth lnhibition value (TGl)
96.85%
Positive HER2 expression (HER2+++/++)
Method Description
3x104 A431 cells were injected subcutaneously into the right shoulder of 4-6-week-old BALB/c nude mice, and when the average tumor size of the mice grew to 140 ~ 150mm3, they were randomly divided into 5 cells in each group. At day 0, day 7, day 14, day 21, intravenous injection of a blank control (blank buffer solution) and a dose of 10mg/kg antibody drug conjugate was administered. The tumor volume was measured at day 0, day 7, day 14, day 21, day 24, day 28, day 32, day 36 and the tumor growth inhibition rate on day 28 of d was calculated.

   Click to Show/Hide
In Vivo Model A431 tumor bearing nude mouse model
Revealed Based on the Cell Line Data
Click To Hide/Show 5 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [2]
Efficacy Data Half Maximal inhibitory Concentration (lC61)
13.7 nM
Positive HER2 expression (HER2+++/++)
Method Description
N87 cells were used as in vitro pharmacodynamic detection systems. An appropriate number of tumor cell lines were inoculated in 96-well plates, incubated in carbon dioxide incubators for 24 hours, and then treated with medicine. The drug was diluted in a medium (the initial concentration of ADC drug was 500nM, the dilution factor was 7 times, there were 8 concentration points, the theoretical coupling ratio (DAR) of toxin and antibody was 8:1, and the actual coupling ratio was roughly 7.5:1, so the initial concentration of toxin was 4.0 uM, 7 times concentration gradient dilution, 8 concentration points). After mixing, it was added into the corresponding cell holes and incubated at 37°C in carbon dioxide incubator for 5 days. After 5 days, 20uL MTS was added to each well (Promega, G3581) reacted for 2 hours, and the absorption value reading at 490nm was taken with an enzyme label. By detecting the activity of dehydrogenase in mitochondria, IC50 was calculated to evaluate the inhibitory effect of ADC drugs on the proliferation of tumor cells.

   Click to Show/Hide
In Vitro Model Gastric tubular adenocarcinoma N87 cells CVCL_1603
Experiment 2 Reporting the Activity Date of This ADC [2]
Efficacy Data Half Maximal inhibitory Concentration (lC61)
15.09 nM
Positive HER2 and EGFR expression (HER2 and EGFR+++/++)
Method Description
SW620 cells were used as in vitro pharmacodynamic detection systems. An appropriate number of tumor cell lines were inoculated in 96-well plates, incubated in carbon dioxide incubators for 24 hours, and then treated with medicine. The drug was diluted in a medium (the initial concentration of ADC drug was 500nM, the dilution factor was 7 times, there were 8 concentration points, the theoretical coupling ratio (DAR) of toxin and antibody was 8:1, and the actual coupling ratio was roughly 7.5:1, so the initial concentration of toxin was 4.0 uM, 7 times concentration gradient dilution, 8 concentration points). After mixing, it was added into the corresponding cell holes and incubated at 37°C in carbon dioxide incubator for 5 days. After 5 days, 20uL MTS was added to each well (Promega, G3581) reacted for 2 hours, and the absorption value reading at 490nm was taken with an enzyme label. By detecting the activity of dehydrogenase in mitochondria, IC50 was calculated to evaluate the inhibitory effect of ADC drugs on the proliferation of tumor cells.

   Click to Show/Hide
In Vitro Model Colon adenocarcinoma SW620 cells CVCL_0547
Experiment 3 Reporting the Activity Date of This ADC [2]
Efficacy Data Half Maximal inhibitory Concentration (lC61)
18.92 nM
Positive HER2 expression (HER2+++/++)
Method Description
Fadu cells were used as in vitro pharmacodynamic detection systems. An appropriate number of tumor cell lines were inoculated in 96-well plates, incubated in carbon dioxide incubators for 24 hours, and then treated with medicine. The drug was diluted in a medium (the initial concentration of ADC drug was 500nM, the dilution factor was 7 times, there were 8 concentration points, the theoretical coupling ratio (DAR) of toxin and antibody was 8:1, and the actual coupling ratio was roughly 7.5:1, so the initial concentration of toxin was 4.0 uM, 7 times concentration gradient dilution, 8 concentration points). After mixing, it was added into the corresponding cell holes and incubated at 37°C in carbon dioxide incubator for 5 days. After 5 days, 20uL MTS was added to each well (Promega, G3581) reacted for 2 hours, and the absorption value reading at 490nm was taken with an enzyme label. By detecting the activity of dehydrogenase in mitochondria, IC50 was calculated to evaluate the inhibitory effect of ADC drugs on the proliferation of tumor cells.

   Click to Show/Hide
In Vitro Model Hypopharyngeal squamous cell carcinoma FaDu cells CVCL_1218
Experiment 4 Reporting the Activity Date of This ADC [2]
Efficacy Data Half Maximal inhibitory Concentration (lC61)
49.85 nM
Positive HER2 expression (HER2+++/++)
Method Description
BXPC-3 cells were used as in vitro pharmacodynamic detection systems. An appropriate number of tumor cell lines were inoculated in 96-well plates, incubated in carbon dioxide incubators for 24 hours, and then treated with medicine. The drug was diluted in a medium (the initial concentration of ADC drug was 500nM, the dilution factor was 7 times, there were 8 concentration points, the theoretical coupling ratio (DAR) of toxin and antibody was 8:1, and the actual coupling ratio was roughly 7.5:1, so the initial concentration of toxin was 4.0 uM, 7 times concentration gradient dilution, 8 concentration points). After mixing, it was added into the corresponding cell holes and incubated at 37°C in carbon dioxide incubator for 5 days. After 5 days, 20uL MTS was added to each well (Promega, G3581) reacted for 2 hours, and the absorption value reading at 490nm was taken with an enzyme label. By detecting the activity of dehydrogenase in mitochondria, IC50 was calculated to evaluate the inhibitory effect of ADC drugs on the proliferation of tumor cells.

   Click to Show/Hide
In Vitro Model Pancreatic ductal adenocarcinoma BxPC-3 cells CVCL_0186
Experiment 5 Reporting the Activity Date of This ADC [2]
Efficacy Data Half Maximal inhibitory Concentration (lC61)
56.7 nM
Positive HER2 and EGFR expression (HER2 and EGFR+++/++)
Method Description
A431 cells were used as in vitro pharmacodynamic detection systems. An appropriate number of tumor cell lines were inoculated in 96-well plates, incubated in carbon dioxide incubators for 24 hours, and then treated with medicine. The drug was diluted in a medium (the initial concentration of ADC drug was 500nM, the dilution factor was 7 times, there were 8 concentration points, the theoretical coupling ratio (DAR) of toxin and antibody was 8:1, and the actual coupling ratio was roughly 7.5:1, so the initial concentration of toxin was 4.0 uM, 7 times concentration gradient dilution, 8 concentration points). After mixing, it was added into the corresponding cell holes and incubated at 37°C in carbon dioxide incubator for 5 days. After 5 days, 20uL MTS was added to each well (Promega, G3581) reacted for 2 hours, and the absorption value reading at 490nm was taken with an enzyme label. By detecting the activity of dehydrogenase in mitochondria, IC50 was calculated to evaluate the inhibitory effect of ADC drugs on the proliferation of tumor cells.

   Click to Show/Hide
In Vitro Model Skin squamous cell carcinoma A431 cells CVCL_0037
wO2023232144A1ADC29 [Investigative]
Discovered Using Cell Line-derived Xenograft Model
Click To Hide/Show 2 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Max Tumor Growth lnhibition value (TGl) (d) < 20% Positive TLR expression (TLR+++/++)
Method Description
ADC29 was tested in mouse M38 CRC model in C57BL/6 mice, 2.5 mg/kg, QWx2, IV
In Vivo Model Mouse MC38 CRC Model in C57BL/6 Mice
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Max Tumor Growth lnhibition value (TGl) (d) < 20% Positive TLR expression (TLR+++/++)
Method Description
ADC29 was tested in mouse M38 CRC model in C57BL/6 mice, 2.5 mg/kg, QWx2, IV
In Vivo Model Mouse MC38 CRC Model in C57BL/6 Mice
wO2023232144A1ADC30 [Investigative]
Discovered Using Cell Line-derived Xenograft Model
Click To Hide/Show 1 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Max Tumor Growth lnhibition value (TGl) (d) > 50% Positive TLR expression (TLR+++/++)
Method Description
ADC30 was tested in mouse M38 CRC model in C57BL/6 mice, 3 mg/kg, QWx3, IV
In Vivo Model Mouse MC38 CRC Model in C57BL/6 Mice
cN113943310A ADC-11 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 5 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [2]
Efficacy Data Half Maximal inhibitory Concentration (lC60)
9.03 nM
Positive HER2 and EGFR expression (HER2 and EGFR+++/++)
Method Description
SW620 cells were used as in vitro pharmacodynamic detection systems. An appropriate number of tumor cell lines were inoculated in 96-well plates, incubated in carbon dioxide incubators for 24 hours, and then treated with medicine. The drug was diluted in a medium (the initial concentration of ADC drug was 500nM, the dilution factor was 7 times, there were 8 concentration points, the theoretical coupling ratio (DAR) of toxin and antibody was 8:1, and the actual coupling ratio was roughly 7.5:1, so the initial concentration of toxin was 4.0 uM, 7 times concentration gradient dilution, 8 concentration points). After mixing, it was added into the corresponding cell holes and incubated at 37°C in carbon dioxide incubator for 5 days. After 5 days, 20uL MTS was added to each well (Promega, G3581) reacted for 2 hours, and the absorption value reading at 490nm was taken with an enzyme label. By detecting the activity of dehydrogenase in mitochondria, IC50 was calculated to evaluate the inhibitory effect of ADC drugs on the proliferation of tumor cells.

   Click to Show/Hide
In Vitro Model Colon adenocarcinoma SW620 cells CVCL_0547
Experiment 2 Reporting the Activity Date of This ADC [2]
Efficacy Data Half Maximal inhibitory Concentration (lC60)
11.86 nM
Positive HER2 expression (HER2+++/++)
Method Description
N87 cells were used as in vitro pharmacodynamic detection systems. An appropriate number of tumor cell lines were inoculated in 96-well plates, incubated in carbon dioxide incubators for 24 hours, and then treated with medicine. The drug was diluted in a medium (the initial concentration of ADC drug was 500nM, the dilution factor was 7 times, there were 8 concentration points, the theoretical coupling ratio (DAR) of toxin and antibody was 8:1, and the actual coupling ratio was roughly 7.5:1, so the initial concentration of toxin was 4.0 uM, 7 times concentration gradient dilution, 8 concentration points). After mixing, it was added into the corresponding cell holes and incubated at 37°C in carbon dioxide incubator for 5 days. After 5 days, 20uL MTS was added to each well (Promega, G3581) reacted for 2 hours, and the absorption value reading at 490nm was taken with an enzyme label. By detecting the activity of dehydrogenase in mitochondria, IC50 was calculated to evaluate the inhibitory effect of ADC drugs on the proliferation of tumor cells.

   Click to Show/Hide
In Vitro Model Gastric tubular adenocarcinoma N87 cells CVCL_1603
Experiment 3 Reporting the Activity Date of This ADC [2]
Efficacy Data Half Maximal inhibitory Concentration (lC60)
13.57 nM
Positive HER2 expression (HER2+++/++)
Method Description
Fadu cells were used as in vitro pharmacodynamic detection systems. An appropriate number of tumor cell lines were inoculated in 96-well plates, incubated in carbon dioxide incubators for 24 hours, and then treated with medicine. The drug was diluted in a medium (the initial concentration of ADC drug was 500nM, the dilution factor was 7 times, there were 8 concentration points, the theoretical coupling ratio (DAR) of toxin and antibody was 8:1, and the actual coupling ratio was roughly 7.5:1, so the initial concentration of toxin was 4.0 uM, 7 times concentration gradient dilution, 8 concentration points). After mixing, it was added into the corresponding cell holes and incubated at 37°C in carbon dioxide incubator for 5 days. After 5 days, 20uL MTS was added to each well (Promega, G3581) reacted for 2 hours, and the absorption value reading at 490nm was taken with an enzyme label. By detecting the activity of dehydrogenase in mitochondria, IC50 was calculated to evaluate the inhibitory effect of ADC drugs on the proliferation of tumor cells.

   Click to Show/Hide
In Vitro Model Hypopharyngeal squamous cell carcinoma FaDu cells CVCL_1218
Experiment 4 Reporting the Activity Date of This ADC [2]
Efficacy Data Half Maximal inhibitory Concentration (lC60)
35.66 nM
Positive HER2 expression (HER2+++/++)
Method Description
BXPC-3 cells were used as in vitro pharmacodynamic detection systems. An appropriate number of tumor cell lines were inoculated in 96-well plates, incubated in carbon dioxide incubators for 24 hours, and then treated with medicine. The drug was diluted in a medium (the initial concentration of ADC drug was 500nM, the dilution factor was 7 times, there were 8 concentration points, the theoretical coupling ratio (DAR) of toxin and antibody was 8:1, and the actual coupling ratio was roughly 7.5:1, so the initial concentration of toxin was 4.0 uM, 7 times concentration gradient dilution, 8 concentration points). After mixing, it was added into the corresponding cell holes and incubated at 37°C in carbon dioxide incubator for 5 days. After 5 days, 20uL MTS was added to each well (Promega, G3581) reacted for 2 hours, and the absorption value reading at 490nm was taken with an enzyme label. By detecting the activity of dehydrogenase in mitochondria, IC50 was calculated to evaluate the inhibitory effect of ADC drugs on the proliferation of tumor cells.

   Click to Show/Hide
In Vitro Model Pancreatic ductal adenocarcinoma BxPC-3 cells CVCL_0186
Experiment 5 Reporting the Activity Date of This ADC [2]
Efficacy Data Half Maximal inhibitory Concentration (lC60)
43.81 nM
Positive HER2 and EGFR expression (HER2 and EGFR+++/++)
Method Description
A431 cells were used as in vitro pharmacodynamic detection systems. An appropriate number of tumor cell lines were inoculated in 96-well plates, incubated in carbon dioxide incubators for 24 hours, and then treated with medicine. The drug was diluted in a medium (the initial concentration of ADC drug was 500nM, the dilution factor was 7 times, there were 8 concentration points, the theoretical coupling ratio (DAR) of toxin and antibody was 8:1, and the actual coupling ratio was roughly 7.5:1, so the initial concentration of toxin was 4.0 uM, 7 times concentration gradient dilution, 8 concentration points). After mixing, it was added into the corresponding cell holes and incubated at 37°C in carbon dioxide incubator for 5 days. After 5 days, 20uL MTS was added to each well (Promega, G3581) reacted for 2 hours, and the absorption value reading at 490nm was taken with an enzyme label. By detecting the activity of dehydrogenase in mitochondria, IC50 was calculated to evaluate the inhibitory effect of ADC drugs on the proliferation of tumor cells.

   Click to Show/Hide
In Vitro Model Skin squamous cell carcinoma A431 cells CVCL_0037
isumab01-C2a [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 4 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [3]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.639 pM
High FRa expression (FRa +++)
Method Description
A Cell line test on Jeg3
In Vitro Model Gestational choriocarcinoma Jeg3 cells CVCL_0363
Experiment 2 Reporting the Activity Date of This ADC [3]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
6 pM
High FRa expression (FRa +++)
Method Description
A Cell line test on H2110
In Vitro Model Lung non-small cell carcinoma H2110 cells CVCL_1530
Experiment 3 Reporting the Activity Date of This ADC [3]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
10 pM
High FRa expression (FRa +++)
Method Description
A Cell line test on OVCAR-3
In Vitro Model Ovarian serous adenocarcinoma OVCAR-3 cells CVCL_0465
Experiment 4 Reporting the Activity Date of This ADC [3]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
138 pM
High FRa expression (FRa +++)
Method Description
A Cell line test on OV90
In Vitro Model Adenocarcinoma of ovary, Ovarian adenocarcinoma OV90 cells CVCL_3768
isumab01-C2b [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 4 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [3]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.639 pM
High FRa expression (FRa +++)
Method Description
A Cell line test on Jeg3
In Vitro Model Gestational choriocarcinoma Jeg3 cells CVCL_0363
Experiment 2 Reporting the Activity Date of This ADC [3]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
6 pM
High FRa expression (FRa +++)
Method Description
A Cell line test on H2110
In Vitro Model Lung non-small cell carcinoma H2110 cells CVCL_1530
Experiment 3 Reporting the Activity Date of This ADC [3]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
10 pM
High FRa expression (FRa +++)
Method Description
A Cell line test on OVCAR-3
In Vitro Model Ovarian serous adenocarcinoma OVCAR-3 cells CVCL_0465
Experiment 4 Reporting the Activity Date of This ADC [3]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
138 pM
High FRa expression (FRa +++)
Method Description
A Cell line test on OV90
In Vitro Model Adenocarcinoma of ovary, Ovarian adenocarcinoma OV90 cells CVCL_3768
References
Ref 1 Drug conjugates of imidazoquinoline amine derivatives, compositions and methods thereof
Ref 2 Deuterated camptothecin derivatives and their antibody-drug conjugates
Ref 3 Antibody-drug conjugate compounds, and methods of use and treatment
