General Information of This Payload
Payload ID
PAY0NEEAT
Name
Exatecan-aminoethoxy
Synonyms
compound 52
   Click to Show/Hide
Target DNA topoisomerase I (TOP1)
Structure
Formula
C24H24FN3O5
Isosmiles
O=C1[C@](O)(CC)C2=C(CO1)C(N3CC4=C(CC)C5=CC(OCCN)=C(F)C=C5N=C4C3=C2)=O
InChI
InChI=1S/C24H24FN3O5/c1-3-12-13-7-20(32-6-5-26)17(25)9-18(13)27-21-14(12)10-28-19(21)8-16-15(22(28)29)11-33-23(30)24(16,31)4-2/h7-9,31H,3-6,10-11,26H2,1-2H3/t24-/m0/s1
InChIKey
FLNFVMOWJNIWSX-DEOSSOPVSA-N
Pharmaceutical Properties
Molecule Weight
453.47
Polar area
116.67
Complexity
1343.18167
xlogp Value
2.1186
Heavy Count
33
Rot Bonds
5
Hbond acc
8
Hbond Donor
2
Each Antibody-drug Conjugate Related to This Payload
Full Information of The Activity Data of The ADC(s) Related to This Payload
wO2024239281A1 C117 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.08 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
PC-3-4H7 cell is both Steap1and PSMA antigen high express cells. To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma PC-3-4H7 cells Homo sapiens
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.095 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
C4-2B is both Steap1 and PSMA antigen high express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma C4-2B cells CVCL_4784
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
11.9 nM
Low Steap1 and PSMA expression (Steap1 and PSMA+)
Method Description
22RV1 is both Steapl and PSMA antigen low express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
wO2024239281A1 C207C [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.08 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
PC-3-4H7 cell is both Steap1and PSMA antigen high express cells. To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma PC-3-4H7 cells Homo sapiens
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.087 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
C4-2B is both Steap1 and PSMA antigen high express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma C4-2B cells CVCL_4784
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
9.45 nM
Low Steap1 and PSMA expression (Steap1 and PSMA+)
Method Description
22RV1 is both Steapl and PSMA antigen low express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
wO2024239281A1 C207 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.085 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
C4-2B is both Steap1 and PSMA antigen high express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma C4-2B cells CVCL_4784
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.11 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
PC-3-4H7 cell is both Steap1and PSMA antigen high express cells. To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma PC-3-4H7 cells Homo sapiens
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
10.9 nM
Low Steap1 and PSMA expression (Steap1 and PSMA+)
Method Description
22RV1 is both Steapl and PSMA antigen low express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
wO2024239281A1 C054 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.135 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
C4-2B is both Steap1 and PSMA antigen high express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma C4-2B cells CVCL_4784
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.821 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
PC-3-4H7 cell is both Steap1and PSMA antigen high express cells. To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma PC-3-4H7 cells Homo sapiens
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
255.6 nM
Low Steap1 and PSMA expression (Steap1 and PSMA+)
Method Description
22RV1 is both Steapl and PSMA antigen low express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
wO2024239281A1 C257 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.39 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
PC-3-4H7 cell is both Steap1and PSMA antigen high express cells. To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma PC-3-4H7 cells Homo sapiens
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.47 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
C4-2B is both Steap1 and PSMA antigen high express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma C4-2B cells CVCL_4784
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
24.5 nM
Low Steap1 and PSMA expression (Steap1 and PSMA+)
Method Description
22RV1 is both Steapl and PSMA antigen low express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
wO2024239281A1 C266C [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.56 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
PC-3-4H7 cell is both Steap1and PSMA antigen high express cells. To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma PC-3-4H7 cells Homo sapiens
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.72 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
C4-2B is both Steap1 and PSMA antigen high express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma C4-2B cells CVCL_4784
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
27.5 nM
Low Steap1 and PSMA expression (Steap1 and PSMA+)
Method Description
22RV1 is both Steapl and PSMA antigen low express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
wO2024239281A1 C266 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.68 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
PC-3-4H7 cell is both Steap1and PSMA antigen high express cells. To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma PC-3-4H7 cells Homo sapiens
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.75 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
C4-2B is both Steap1 and PSMA antigen high express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma C4-2B cells CVCL_4784
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
28.9 nM
Low Steap1 and PSMA expression (Steap1 and PSMA+)
Method Description
22RV1 is both Steapl and PSMA antigen low express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
wO2024239281A1 C263 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.81 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
PC-3-4H7 cell is both Steap1and PSMA antigen high express cells. To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma PC-3-4H7 cells Homo sapiens
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.85 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
C4-2B is both Steap1 and PSMA antigen high express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma C4-2B cells CVCL_4784
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
68.3 nM
Low Steap1 and PSMA expression (Steap1 and PSMA+)
Method Description
22RV1 is both Steapl and PSMA antigen low express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
wO2024239281A1 C269C [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.89 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
PC-3-4H7 cell is both Steap1and PSMA antigen high express cells. To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma PC-3-4H7 cells Homo sapiens
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
1.07 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
C4-2B is both Steap1 and PSMA antigen high express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma C4-2B cells CVCL_4784
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
51.8 nM
Low Steap1 and PSMA expression (Steap1 and PSMA+)
Method Description
22RV1 is both Steapl and PSMA antigen low express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
wO2024239281A1 C269 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
0.95 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
PC-3-4H7 cell is both Steap1and PSMA antigen high express cells. To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma PC-3-4H7 cells Homo sapiens
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
1.25 nM
High Steap1 and PSMA expression (Steapl and PSMA +++)
Method Description
C4-2B is both Steap1 and PSMA antigen high express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma C4-2B cells CVCL_4784
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
52.5 nM
Low Steap1 and PSMA expression (Steap1 and PSMA+)
Method Description
22RV1 is both Steapl and PSMA antigen low express cells.To run the assay,the cells (180 ul,6000cells)were added to each well in a 96-well plate and incubated for 24 hours at 37°C with 5%CO 2. Next,the cells were treated with test compounds (20ul)at various concentrations in appropriate cell culture medium (total volume,0.2 mL).The control wells contain cells and the medium but lack the test compounds.The plates were incubated for 120 hours at 37°C with 5%CO 2.MTT (5 mg/mL)was then added to the wells (20ul)and the plates were incubated for 1.5 hr at 37°C.The medium was carefully removed and DMSO (180ul)was added afterward.After it was shaken for 15min, the absorbance was measured at 490 nm and 570 nm with a reference filter of 620 nm.The inhibition% was calculated according to the following equation:inhibition%=[1- (assay-blank)/ (control-blank)]× 100.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
References
Ref 1 Targeted treatment of prostate cancers and other tumors by an antibody-drug conjugate
