General Information of This Linker
Linker ID
LIN0RYKTT
Linker Name
A polyethylene glycol-modified branched-link agent
Linker Type
Cathepsin-cleavable linker
Antibody-Linker Relation
Cleavable
Structure
Formula
C49H80N6O16
Isosmiles
C[C@H](NC([C@@H](NC([C@@H](NC(CCCCCN1C(C=CC1=O)=O)=O)CCCCNC(CCOCCOCCOCCOCCOCCOCCOCCOC)=O)=O)C(C)C)=O)C(NC2=CC=C(CO)C=C2)=O
InChI
InChI=1S/C49H80N6O16/c1-37(2)46(49(63)51-38(3)47(61)52-40-14-12-39(36-56)13-15-40)54-48(62)41(53-43(58)11-6-5-9-20-55-44(59)16-17-45(55)60)10-7-8-19-50-42(57)18-21-65-24-25-67-28-29-69-32-33-71-35-34-70-31-30-68-27-26-66-23-22-64-4/h12-17,37-38,41,46,56H,5-11,18-36H2,1-4H3,(H,50,57)(H,51,63)(H,52,61)(H,53,58)(H,54,62)/t38-,41-,46-/m0/s1
InChIKey
AHVBLALLZOGMCT-GSYYMGFTSA-N
Pharmaceutical Properties
Molecule Weight
1009.205
Polar area
276.95
Complexity
1618.296769
xlogp Value
1.1723
Heavy Count
71
Rot Bonds
44
Hbond acc
16
Hbond Donor
6
Each Antibody-drug Conjugate Related to This Linker
Full Information of The Activity Data of The ADC(s) Related to This Linker
40285886 7300-LP2004 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 1 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
39.74 nM
Method Description
SHP-77 cells were grown in RPMI-1640 medium supplemented with 10% FBS and 1 ug/mL puromycin at 37 °C in a 5% CO2 incubator. SHP-77 cells were dissociated using TrypLETM Express Enzyme (Thermo Fisher Scientific, Waltham, MA, USA) and, after counting, the cells were resuspended in RPMI-1640 medium supplemented with 10% FBS at a density of 3 × 104 cells/mL. The cells were plated in 96-well plates and incubated at 37 °C for 24 h. ADCs and payloads were diluted separately and added to the 96-well cell culture plates containing cells, followed by incubation in a 5% CO2 incubator for 5 days. A multifunctional microplate reader was used, and the absorbance was measured at 450 nm with a reference wavelength of 630 nm. The IC50 values were calculated using GraphPad Prism 10.1.2 software.

   Click to Show/Hide
In Vitro Model Small cell lung carcinoma SHP-77 cells CVCL_1693
References
Ref 1 Design, Synthesis, and Evaluation of Camptothecin-Based Antibody-Drug Conjugates with High Hydrophilicity and Structural Stability
