General Information of This Linker
Linker ID
LIN0QABRK
Linker Name
CN119317630A ADC-C9 Linker
Linker Type
Cathepsin-cleavable linker
Antibody-Linker Relation
Cleavable
Structure
Formula
C26H40N4O14
Isosmiles
CC([C@H](NC(CCCCCN1C(CCC1=O)=O)=O)C(N[C@@H](CO[C@H]2[C@H](O)[C@@H](O)[C@H](O)[C@@H](C(O)=O)O2)C(NCC(O)=O)=O)=O)C
InChI
InChI=1S/C26H40N4O14/c1-12(2)18(29-14(31)6-4-3-5-9-30-15(32)7-8-16(30)33)24(40)28-13(23(39)27-10-17(34)35)11-43-26-21(38)19(36)20(37)22(44-26)25(41)42/h12-13,18-22,26,36-38H,3-11H2,1-2H3,(H,27,39)(H,28,40)(H,29,31)(H,34,35)(H,41,42)/t13-,18-,19-,20-,21+,22-,26+/m0/s1
InChIKey
TVOXABWMIDOSSH-OWNQYCQCSA-N
Pharmaceutical Properties
Molecule Weight
632.62
Polar area
278.43
Complexity
1012.256546
xlogp Value
-3.569
Heavy Count
44
Rot Bonds
17
Hbond acc
12
Hbond Donor
8
Each Antibody-drug Conjugate Related to This Linker
Full Information of The Activity Data of The ADC(s) Related to This Linker
FDA028-LE14 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 6 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
37.2 nM
Method Description
22Rv1 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
41.2 nM
Method Description
SW620 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC65 results were calculated.

   Click to Show/Hide
In Vitro Model Colon adenocarcinoma SW620 cells CVCL_0547
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
43.12 nM
Method Description
NCI-H820 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Lung papillary adenocarcinoma NCI-H820 cells CVCL_1592
Experiment 4 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
55.75 nM
Method Description
OVCAR-8 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC64 results were calculated.

   Click to Show/Hide
In Vitro Model High grade ovarian serous adenocarcinoma OVCAR-8 cells CVCL_1629
Experiment 5 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
70.13 nM
Method Description
HCC827 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC64 results were calculated.

   Click to Show/Hide
In Vitro Model Lung adenocarcinoma HCC827 cells CVCL_2063
Experiment 6 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
93.28 nM
Method Description
LNCaP (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma LNCaP cells CVCL_0395
FDA029-LE14 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 6 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
37.6 nM
Method Description
22Rv1 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
41.6 nM
Method Description
SW620 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC68 results were calculated.

   Click to Show/Hide
In Vitro Model Colon adenocarcinoma SW620 cells CVCL_0547
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
42.23 nM
Method Description
NCI-H820 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Lung papillary adenocarcinoma NCI-H820 cells CVCL_1592
Experiment 4 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
55.87 nM
Method Description
OVCAR-8 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC64 results were calculated.

   Click to Show/Hide
In Vitro Model High grade ovarian serous adenocarcinoma OVCAR-8 cells CVCL_1629
Experiment 5 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
70.25 nM
Method Description
HCC827 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC64 results were calculated.

   Click to Show/Hide
In Vitro Model Lung adenocarcinoma HCC827 cells CVCL_2063
Experiment 6 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
93.32 nM
Method Description
LNCaP (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma LNCaP cells CVCL_0395
FDA026-LE12 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 5 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
37.8 nM
Method Description
SK-BR-3 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Breast adenocarcinoma SK-BR-3 cells CVCL_0033
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
38.67 nM
Method Description
NCI-H820 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Lung papillary adenocarcinoma NCI-H820 cells CVCL_1592
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
52.32 nM
Method Description
22Rv1 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
Experiment 4 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
56.33 nM
Method Description
SW620 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Colon adenocarcinoma SW620 cells CVCL_0547
Experiment 5 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
97.64 nM
Method Description
LNCaP (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma LNCaP cells CVCL_0395
FDA028-LE12 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 5 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
38.2 nM
Method Description
SK-BR-3 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Breast adenocarcinoma SK-BR-3 cells CVCL_0033
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
38.76 nM
Method Description
NCI-H820 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Lung papillary adenocarcinoma NCI-H820 cells CVCL_1592
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
55.3 nM
Method Description
22Rv1 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
Experiment 4 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
56.45 nM
Method Description
SW620 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC63 results were calculated.

   Click to Show/Hide
In Vitro Model Colon adenocarcinoma SW620 cells CVCL_0547
Experiment 5 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
96.5 nM
Method Description
LNCaP (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma LNCaP cells CVCL_0395
FDA029-LE12 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 5 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
38.45 nM
Method Description
SK-BR-3 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Breast adenocarcinoma SK-BR-3 cells CVCL_0033
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
38.68 nM
Method Description
NCI-H820 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Lung papillary adenocarcinoma NCI-H820 cells CVCL_1592
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
55.34 nM
Method Description
22Rv1 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
Experiment 4 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
56.52 nM
Method Description
SW620 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC66 results were calculated.

   Click to Show/Hide
In Vitro Model Colon adenocarcinoma SW620 cells CVCL_0547
Experiment 5 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
96.8 nM
Method Description
LNCaP (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma LNCaP cells CVCL_0395
FDA029-LE13 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 5 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
42.35 nM
Method Description
SK-BR-3 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Breast adenocarcinoma SK-BR-3 cells CVCL_0033
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
54.56 nM
Method Description
OVCAR-8 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC64 results were calculated.

   Click to Show/Hide
In Vitro Model High grade ovarian serous adenocarcinoma OVCAR-8 cells CVCL_1629
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
66.1 nM
Method Description
22Rv1 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
Experiment 4 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
67.75 nM
Method Description
SW620 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC67 results were calculated.

   Click to Show/Hide
In Vitro Model Colon adenocarcinoma SW620 cells CVCL_0547
Experiment 5 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
88.34 nM
Method Description
LNCaP (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma LNCaP cells CVCL_0395
FDA026-LE13 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 5 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
42.4 nM
Method Description
SK-BR-3 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Breast adenocarcinoma SK-BR-3 cells CVCL_0033
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
54.33 nM
Method Description
OVCAR-8 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC64 results were calculated.

   Click to Show/Hide
In Vitro Model High grade ovarian serous adenocarcinoma OVCAR-8 cells CVCL_1629
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
64.36 nM
Method Description
22Rv1 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
Experiment 4 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
67.54 nM
Method Description
SW620 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC51 results were calculated.

   Click to Show/Hide
In Vitro Model Colon adenocarcinoma SW620 cells CVCL_0547
Experiment 5 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
87.77 nM
Method Description
LNCaP (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma LNCaP cells CVCL_0395
FDA028-LE13 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 5 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
42.4 nM
Method Description
SK-BR-3 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Breast adenocarcinoma SK-BR-3 cells CVCL_0033
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
54.45 nM
Method Description
OVCAR-8 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC64 results were calculated.

   Click to Show/Hide
In Vitro Model High grade ovarian serous adenocarcinoma OVCAR-8 cells CVCL_1629
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
65.2 nM
Method Description
22Rv1 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
Experiment 4 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
67.82 nM
Method Description
SW620 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC64 results were calculated.

   Click to Show/Hide
In Vitro Model Colon adenocarcinoma SW620 cells CVCL_0547
Experiment 5 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
88.23 nM
Method Description
LNCaP (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma LNCaP cells CVCL_0395
FDA026-LE21 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 3 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
46.3 nM
Method Description
SK-BR-3 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Breast adenocarcinoma SK-BR-3 cells CVCL_0033
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
89.34 nM
Method Description
NCI-H820 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Lung papillary adenocarcinoma NCI-H820 cells CVCL_1592
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
98.26 nM
Method Description
22Rv1 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
FDA026-LE22 [Investigative]
Revealed Based on the Cell Line Data
Click To Hide/Show 5 Activity Data Related to This Level
Experiment 1 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
52.7 nM
Method Description
SK-BR-3 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Breast adenocarcinoma SK-BR-3 cells CVCL_0033
Experiment 2 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
78.44 nM
Method Description
NCI-H820 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Lung papillary adenocarcinoma NCI-H820 cells CVCL_1592
Experiment 3 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
87.65 nM
Method Description
22Rv1 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.

   Click to Show/Hide
In Vitro Model Prostate carcinoma 22RV1 cells CVCL_1045
Experiment 4 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
89.34 nM
Method Description
OVCAR-8 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC64 results were calculated.

   Click to Show/Hide
In Vitro Model High grade ovarian serous adenocarcinoma OVCAR-8 cells CVCL_1629
Experiment 5 Reporting the Activity Date of This ADC [1]
Efficacy Data Half Maximal inhibitory Concentration (lC50)
96.75 nM
Method Description
HCC827 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC64 results were calculated.

   Click to Show/Hide
In Vitro Model Lung adenocarcinoma HCC827 cells CVCL_2063
References
Ref 1 Antibody-drug conjugates, intermediates, preparation methods and uses
