Linker Information
General Information of This Linker
| Linker ID |
LIN0DWRJM
|
|||||
|---|---|---|---|---|---|---|
| Linker Name |
FDA026-LE20 linker
|
|||||
| Linker Type |
Cathepsin-cleavable linker
|
|||||
| Antibody-Linker Relation |
Cleavable
|
|||||
| Structure |
|
|||||
| Formula |
C47H74N8O15
|
|||||
| Isosmiles |
C[C@H](NC([C@@H](NC(CCOCCOCCOCCOCCOCCOCCOCCOCCN1N=NC(CNC(CCCCCN2C(C=CC2=O)=O)=O)=C1)=O)C(C)C)=O)C(NC3=CC=C(CO)C=C3)=O
|
|||||
| InChI |
InChI=1S/C47H74N8O15/c1-36(2)45(47(62)49-37(3)46(61)50-39-10-8-38(35-56)9-11-39)51-42(58)14-17-63-19-21-65-23-25-67-27-29-69-31-32-70-30-28-68-26-24-66-22-20-64-18-16-54-34-40(52-53-54)33-48-41(57)7-5-4-6-15-55-43(59)12-13-44(55)60/h8-13,34,36-37,45,56H,4-7,14-33,35H2,1-3H3,(H,48,57)(H,49,62)(H,50,61)(H,51,58)/t37-,45-/m0/s1
|
|||||
| InChIKey |
ZRZPABLFLAFJSX-JJXMVLQZSA-N
|
|||||
| Pharmaceutical Properties |
Molecule Weight
|
991.15
|
Polar area
|
278.56
|
||
|
Complexity
|
1745.249805
|
xlogp Value
|
0.6791
|
|||
|
Heavy Count
|
70
|
Rot Bonds
|
42
|
|||
|
Hbond acc
|
18
|
Hbond Donor
|
5
|
|||
Each Antibody-drug Conjugate Related to This Linker
Full Information of The Activity Data of The ADC(s) Related to This Linker
FDA026-LE20 [Investigative]
Revealed Based on the Cell Line Data
| Experiment 1 Reporting the Activity Date of This ADC | [1] | ||||
| Efficacy Data | Half Maximal inhibitory Concentration (lC50) |
46.15 nM
|
|||
| Method Description |
SK-BR-3 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC50 results were calculated.
Click to Show/Hide
|
||||
| In Vitro Model | Breast adenocarcinoma | SK-BR-3 cells | CVCL_0033 | ||
| Experiment 2 Reporting the Activity Date of This ADC | [1] | ||||
| Efficacy Data | Half Maximal inhibitory Concentration (lC50) |
52.33 nM
|
|||
| Method Description |
SW620 (ATCC) cells were selected as the cell line for in vitro activity detection experiments. 2000 cells were inoculated into each well of a 96-well cell culture plate and cultured for 20-24 hours. The antibody-drug conjugate prepared according to the method in Example 3 was formulated with L15 cell culture medium containing 10% FBS into 11 concentration gradients of test solution: 1000, 166.7, 55.6, 18.6, 6.17, 2.06, 0.69, 0.23, 0.08, 0.008 and OnM. 100 ul of the diluted test solution per well was added to the culture plate containing the inoculated cells and incubated in a 37°C, 5% CO, incubator for 144 hours. Then, CellTiter-Glo® Luminescent Cell Viability Assay Reagent (50 ul/well) was added, and the mixture was shaken at 500 rpm at room temperature for 10 minutes. The data were read using a SpectraMaxL microplate reader (OD570nm, with 2-second interval readings), and the IC58 results were calculated.
Click to Show/Hide
|
||||
| In Vitro Model | Colon adenocarcinoma | SW620 cells | CVCL_0547 | ||
